Product ShowYour Postion：LeYao Engineering Equipment > FV34 thin single plate check valve
Name：FV34 Thin wafer swing check valve
show：1220
Size：1.5"-24" /DN40-DN600
Working pressure:Class150/ Class125/PN16/PN25
Working temperature：-20℃- 120℃
Working pressure:Class150/ Class125/PN16/PN25
Flanged standard：GB/T 9113、JB/T 79、
BS 4504、DIN、UNI 2223Working temperature：-20℃- 120℃
Characteristics：
1, Small Volume, light weight, need less space.
2, When install the valve to the pipe flange, the gaskets are optional, the valve has its own sealing O-ring.
3, This valve should be install to the outlet side of the pump to prevent the backflow of the medium. This valve is one way flow direction.
4, Zero Leakage since the sealing is resilient.
